  1. Good evening, I don't know if your are in Europe or somewhere else, but If you need I can help you to repair it. ( I am in France ) Bye
  2. Hello, I have printed this: https://www.thingiverse.com/thing:4617648 Then use a noctua fan. So no need to cut HDD carrier. bye
  3. Hello Dave, can we use this patched 5003.67 even if we don't have the MakeMhz HDMI ? I make some 128 Mb upgrade with small chineese wii2hdmi adapter after removing xbox video connector. I have also a hdmi pbc from Lukas (N64Freaks), top quality. bye
  4. Hello, I am sorry to reply s lately, but it is sold. I prepare some Xbox very often, but shipping to USA in incredibely expensive, I don't know why, but the cheaper is about 70 euros, 90 dollars. bye
  5. Because it exist a 3d printed parts that helps to keep inplace adapter. bye
  6. I use this one: https://www.aliexpress.com/item/33010569030.html?spm=a2g0o.productlist.0.0.7aea1881A8lKYx&algo_pvid=b86edc03-ac1b-4fcd-a5b4-2dbe6143d772&algo_expid=b86edc03-ac1b-4fcd-a5b4-2dbe6143d772-2&btsid=2100bdd716142012449321075eb0fc&ws_ab_test=searchweb0_0,searchweb201602_,searchweb201603_
  7. I usually work chineese adapter, but I change the capacitor on it, because 2 Tb 3 1/2 needs more power on start. Could you show me a picture of your adapter ? bye
  8. I would do the same for a blue !
  9. or use x2.5035.67.v16 if you have a 512 kb bios bank
  10. Hello, take first the bios called Evox M8+ 1.6 67 then use EVTOOL, and change what you need. bye
  11. Hello, the cpu caps have to have a very low ESR (internal resistance) and of course at least he same voltage or more, and of course the same capacity. But when I recap an XBox or an Atari PSU or an Amiga 500/2000, I always choose caps with the longest MTBF lifespan. Jackon has not the worst reputation, but they are far from the best. I you want to keep an electronic device for a long time, or if you want to sell it with a maximum of serenity, I would advice you to buy Panasonic FR Series. Yes, i's a bit more expensive, but no so much if you also think to preserve earth by lengthening the lifespan of the product you repair. Last times, I started to also change output psu caps, because even if they are still goods if only speaking about µF, when I checked them about ESR, they were 0.7 ohm whereas the Panasonic were 0.06 ohm, so ten times less. You can look at this nice explaination, also exist in english: https://en.wikipedia.org/wiki/Equivalent_series_resistance This is only an advice, you are really free to do what you want. You have to be really proud to have repaired a nive Xbox. Congratulations, bye
  12. Hello, the cpu caps have to have a very low ESR (internal resistance) and of course at least he same voltage or more, and of course the same capacity. But when I recap an XBox or an Atari PSU or an Amiga 500/2000, I always choose caps with the longest MTBF lifespan. Jackon has not the worst reputation, but they are far from the best. I you want to keep an electronic device for a long time, or if you want to sell it with a maximum of serenity, I would advice you to buy Panasonic FR Series. Yes, i's a bit more expensive, but no so much if you also think to preserve earth by lengthening the lifespan of the product you repair. This is only an advice, you are really free to do what you want. You have to be really proud to have repaired a nive Xbox. Congratulations, bye
  13. Benur75

    Al Ban

    Hello, in this forum, even if you are french, you have to speak / write in english. I am french, and really if you need some help, first try to ask clearly what you want, in english ! Else use google to translate. Moreover, in this world, if you can' write properly in english, you will be lost. bye
  14. Hello GoTeamScotch, where do you live ? If you are in Europ I can send you one, you will just have to pay shipping. bye
  15. Hello, at the end of the rebuild using torrent app, you will obtain a Xbox_Origins_2TB.imgc file, this is a compressend image disk. You will have to use HDD RAW COPY TOOL 1.10 from www.hddguru.com. Pick first imgc file, then choose the right HDD and wait the night long. Put you destination HDD in sata or external sata. Wait and you will have the most delicisious HDD for Xbox
  16. Hello, i have just finished printing it, that's perfect, thanks
  17. Hello, you may know that you need an adapter in order to use a socket 370 CPU. If you ry to put a mobile P3, it wont work. bye
  18. SS_Dave, I did not know that it exists in sticker, very good idea
  19. Hello, I dont know if you have one day repair a car rear windshield in order to make work again unshadow wires ? I jus want to say that you only need to buy a conductiv paint pen like this one. Sorry this is a frenck amazon link, but you will see what I mean: https://www.amazon.fr/Bare-10-conductivité-électrique-Peinture/dp/B00KBXT6JW/ref=pd_lpo_147_t_0/261-1147411-2679701?_encoding=UTF8&pd_rd_i=B00KBXT6JW&pd_rd_r=45d591e0-4cb8-47c8-b83e-81fb6379259c&pd_rd_w=NY5Xy&pd_rd_wg=6mKgm&pf_rd_p=a9e8383d-b25d-45ec-acc2-a094dd781c31&pf_rd_r=AKGF2VBWYP29M226E0V0&psc=1&refRID=AKGF2VBWYP29M226E0V0 bye
  20. Hello, I have a lot of old broken Xbox on which I kept the screw. Other people are maybe not like me but I am not sure you will have a lot of succes. Where do you leave ? If you only need few screws I could send it to you. bye Stephane
  21. You can also use V1.2 and up gpu heatsink. I am in Europe in you need one (for free only shipping) bye
  22. Please keep cool, I don't think you need to get angry like this, this is a forum, there are so many worldwide problem. Love and Peace bye
  23. Hello, please take some time to clean the board, the clocxk capacitor has already leaked. Use IPA, first remove the board from case, to properly clean it. bye
  24. Good evening, as nothing seems to be out of order, I would rather first prepare a new hdd. As this is a debug kit, you could use an unlocked disk only if you boot on the official recovery disk that permit to choose between debug bios and commercial bios. Please look at: https://www.ogxbox.com/forums/index.php?/topic/1881-devkit-recovery-collection/ bye
  25. Hello, first, gently clean your ram pads with flux and a solder cupper remover. Then, install an Aladin XT lite with Xblast lite firmware, you will be able able to boot after each memory added in order to see if you job is ok before going the next chip. Where do you live ? bye
