Alright folks,
Of the numerous aladdin chips i've installed into 1.6 xboxes, i have installed the pin header with pin 4 removed, rebuilt lpc, connected bt->gnd on chip, cut the lframe trace at the xyclops chip and ignored installing the d0->gnd wire. This has always worked fine for me.
Recently i have seen different and conflicting instructions on de-pinning the header. it was suggested to also remove pin 3 (lframe), 6 (5v) and 12 (gnd).
I'm wondering what the benefit is and whether i need to start doing it this way?
I'm presuming pin 6 has been left out so standby power isn't lighting the led, and pin 3 to disable lframe without cutting the trace? why remove the second gnd (pin 12) though?
Just wondering what the consensus was on this, is this a better way to do it, is my usual way now incorrect??
Figured it was time to ask the experts!
Cheers
Hello friends
I opened my Xbox today to see which mod chip is installed because I bought the device used. It turned out to be a Super Aladdin live chip. I would like to install a larger hard drive with 2TB. I've already ordered the adapter and cables. Now I am wondering if I have to flash my BIOS and which one I should use on this chip.
Since I almost never flash, I have to rely on external help. I have already figured out how to format the hard drive with Hexen.
It looks like I have Evolution X as an app on the device, only the sign is not displayed to me when booting. My Xbox says OPENXDK at the bottom.
Thank you in advance for your help.
