By Johny white
So I've just completed my openxenium install along with spi2par2019 / LCD display and Segate 2TB HDD. There are 4 bio on the openxenium which are x2.5035.137 bin, IND-BIOS.5004.67.bin, evox.m8plus.v16.fc.137.bin and Retail Kernel.
If I boot with the evox.m8plus.v16.fc.137.bin bios, the console hangs up on the xbox logo and the word microsoft when its trying to load the dash. If I reset the console by ejecting the disc and closing it, it reboots fine striaght into the dash.
If I use either x2.5035.137.bin or IND-BIOS.5004.67.bin then console boots straight into the dash from the first time. I tried different HDD, different IDE2SATA adapter both chinese and StarTech ones with all giving the same problem. This leads to believe that the issue is with the evox bios.
Any suggestions or idea, should I be using a different evox bios? HDD is formatted with extra G & F partitions, I resized the partions to a smaller size, restarted and then re-partitioned again to the correct size as suggested in a previous post.
Hi all! I'm having some trouble with installing an OpenXenium purchased from MakeMHZ into an Xbox 1.0. I'm relatively new to this, and have surely made some mistakes. When I start it up, it does this: https://imgur.com/a/HTHYrU2
Here's what I know:
Stupidly, I soldered the D0 pad on the modchip to the 1.6 pad - that has been fixed. I don't think this is the issue, because I have a second chip that I did not make this mistake with, and it still does not work. I didn't scrape the solder mask off LPC ports, and really had trouble flowing the joints. The one I'm most concerned with is the bottom right joint of the first photo. Can I run a jump wire from that to one of the nearby test pads? I'm fairly confident the D0 pad on the modchip is correctly connected to D0 on the board - I tested the continuity from the chip to the both points on the board, and was good. I have photos available here: https://imgur.com/a/FX7R43B
Thanks for any info in advance!!
Hello, i bought a used v1.0 xbox some months ago, which i've modded. but lately i've had problems with it.
It manifested by some times i would turn it on and it does the 3 on/offs then christmas lights. Then all of a sudden it can work again for 5 times, next day i turn it on again, and it won't boot. Have to take out the motherboard and inspect my solderjoints, all ok, into the xbox and it might work again, if not repeat process etc. past 2 days i've used it, it's been working perfect then i noticed it just suddenly freezes and throws a high pitch sound on the speakers without me doing anything but just idling in xbmc menu somewhere. And now it won't start sucessfully at all. just christmas lights. And no occasional luck booting it up successfully either.
I installed a aladdin modchip in it and have long been suspecting the solderwork there, since sometimes it boots and sometimes not. But now i'm thinking it might be the PSU that is the root of the problems.
I looked at another thread and did the voltage testing on the 12v plug pin by starting the PSU and not connecting it to the motherboard. All the wires showed correct voltage except two. The blue wire (or grey as it is on the plug pin) is supposed to be 3.3v but shows 0.04v and the yellow wire which is supposed to be 12v but is showing 5.89v. I'm posting a picture of the psu and you can see 1 capacitor that is very bulged, i've marked it with red arrow. Should i swap out these caps with new ones? are they responsible for the incorrect voltage on specifically those 2 pins? Also the big caps on the motherboard is not bulged but i understand they can very well be off also, even it doesn't show to the naked eye. So basically are the problems coming from the PSU or the motherboard, Would it be enough to just swap out the 3 caps on the psu, you think? What about the big black 400V 180uF one? that can be a culprit too? Btw, when i started up the PSU with no load i can hear a sound coming from the big black 400v capacitator. it's buzzingsound with short 10milliseconds stops in between like as if electrolytic fluid is boiling and hissing in there. is that normal? With load it makes a lower clicking sound. it's prob just the hz from the powerline maybe.
