It not a BIOS thing as the same happens when using a X2-5035.67 and IND5004.67

It also does the same with EvloutionX , Dragon ,Origins dashboards

The triggers +back+Black is the same as pressing a reset button on a PC and that causes a full reboot.

As long  xbmc4gamers set as your default dash it will take around 30 seconds to reboot to ready to select a new game.




Cheers

SS Dave


Soft modding is like masturbating, It gets the job done but it's nothing like the real thing.

Link to comment
Share on other sites

1 hour ago, SS_Dave said:

It not a BIOS thing as the same happens when using a X2-5035.67 and IND5004.67

It also does the same with EvloutionX , Dragon ,Origins dashboards

The triggers +back+Black is the same as pressing a reset button on a PC and that causes a full reboot.

As long  xbmc4gamers set as your default dash it will take around 30 to reboot to ready to select a new game.




Cheers

SS Dave


Soft modding is like masturbating, It gets the job done but it's nothing like the real thing.

With evtool you can edit the bios to boot to logo or dash.

Edited by Ging3rguy
Link to comment
Share on other sites

Unlike Coinops where you can use Back+Start to exit the ROM you are playing and return to the Coinops menu I am not aware of any shortcut like that for any Xbox dash (xbmc4gamers, EvolationX,Dragon, Origins 2tb).

Unless you are using a version 1.6 board I would recommend the X2-5035.67 and then edit the  x2config.ini file on E: drive to boot direct to xbmc4gamers

I also set xbmc4gamers to load direct to the user screen unless you have set multiple users .



Cheers

SS Dave


Soft modding is like masturbating, It gets the job done but it's nothing like the real thing.

Link to comment
Share on other sites

11 hours ago, H3is3nb3rg said:

Yes, Hardmodded with OpenXenium, bios is evox_m8.bin

Not sure what igr settings are

IGR is embedded in the bios, you can turn it off and on with some of the dashboards.

You can edit the ind-bios.cfg file to tell which dash to boot to.

If you had a softmod it would boot to your default dash.

here’s an old list of which bios has igr and which options are available. Just scroll down to igr options.
https://web.archive.org/web/20160316051856/http://xbox-scene.com:80/bios_retail.html

  • Like 1
Link to comment
Share on other sites

15 hours ago, H3is3nb3rg said:

Yes, Hardmodded with OpenXenium, bios is evox_m8.bin

Not sure what igr settings are

If you use ind-bios you get a few different igr options, borrowed this list from a thread on xbmx4xbox by Rocky5.

  • Shutdown (Triggers + Back + White)
  • Tray Eject (Triggers + Right Thumb + Dpad UP)
  • Tray Close (Triggers + Right Thumb + Dpad DOWN)
  • Power Cycle (Triggers + Back + X + Black)
  • Soft reset to dashboard (Triggers + Back + Black)
  • Restart current disc (Triggers + Back + start)
Edited by Ging3rguy
  • Like 1
Link to comment
Share on other sites

5 minutes ago, Ging3rguy said:

If you use ind-bios you get a few different igr options, borrowed this list from a thread on xbmx4xbox by Rocky5.

  • Shutdown (Triggers + Back + White)
  • Tray Eject (Triggers + Right Thumb + Dpad UP)
  • Tray Close (Triggers + Right Thumb + Dpad DOWN)
  • Power Cycle (Triggers + Back + X + Black)
  • Soft reset to dashboard (Triggers + Back + Black)
  • Restart current disc (Triggers + Back + start)

shutdown (triggers + black + white)

tray eject (triggers + right thumb + dpad up)

tray close ( triggers + right thumb + dpad down)

power cycle ( triggers + back + x + black)

restart current disk (triggers + back + start)

posted again as pasteing black on black is a bit tricky to read.

  • Like 1
Link to comment
Share on other sites

  • 2 weeks later...
  • 2 months later...

Hey Rocky5,

With the release of XboxHDMI soon, can we expect the utilisation of its CEC functions to turn on and off TVs when the xbox boots and shuts down. Based on what MakeMHz has stated in the discord they will release the nxdk toolchain for developers to implement the feature when its ready.

Is this something your interested in supporting?

Thanks :)

Link to comment
Share on other sites

  • 3 weeks later...

Hey,

Is it normal that xbmc4gamers points to E:\UDATA\09999990 folder but I cannot find that folder. could that be the reason that the app just doesn't boot anymore? It was working fine, took out the hard drive to add more game and now just doesn't start anymore. I've repeated the initial instalation process but cannot solve the issue.

So basically my question is should I have that folder?

Thank you, and amazing work of course.

Edited by Defkyle
wrong wording
Link to comment
Share on other sites

  • 7 months later...

Hey Rocky5, great work on the XMBC4gamers!

Just wanted to ask, is there any way I can edit the background color for the profile select screen within XMBC4gamers?

Or better yet, can I get a skin for it or perhaps some kind of night mode? (I already have nightmode engaged but it only affects within the profiles, not the profile select screen.)



The UI allows me to change the profile color of the background WITHIN a profile, but not at the profile select screen. Since this is the first thing that pops up when I turn on my xbox, I am forced to see this crummy baby blue color that I don't like and everywhere online claims theres no way to change it or customize it. I have a feeling the baby blue value is given via a hex color code within some file somewhere, I do not mind going into a line of code and editing the hex value if necessary, I just want to know where this information is located in order to change it, because this is literally the last thing before I am 100% custom and everything looks nice and shiny and to my liking but currently the baby blue is driving me nuts. I'd personally love a space grey or something.

I also want to mention I have a soft modded xbox.

Thanks :D

Edited by double0zero
Link to comment
Share on other sites

  • 4 months later...

Ok so there's this Disable Edit Mode key combo to enter at the login screen.

I'm at this screen.  Is it not the login screen?


Because pressing the button combo to Enable/Disable Edit Mode:

UP, UP, DOWN, DOWN, LEFT, LEFT, RIGHT, RIGHT & A

simply moves the cursor around the screen selecting different profile icons and upon pressing (A) opens the selected icon.

Link to comment
